ELECTRICAL CHARACTERISTICS (Cont.)

Symbol

Parameter

Test Conditions

Min

Typ

Max

Unit

Ref Out Voltage

Ω

– 2.4

– 2.8

– 3.2

V

Ref Out Temperature

25 k

—

80

—

ppm/

°C

Coefficient

0

Digital

Output High Voltage

3.5

4.3

—

V

Pins 3–16, 18, 19, 20

Output Low Voltage

—

0.2

0.4

V

Output Leakage Current

Pins 3–16 High Impedance

—

±0.01

±1

µA

Control I/O

—

5

—

µA

Pull-Up Current

Mode Input at GND

Control I/O Loading

HBEN, Pin 19; LBEN, Pin 18

—

—

50

pF

Input High Voltage

Pins 18–21, 26, 27

2.5

—

—

V

Referenced to GND

Input Low Voltage

Pins 18-21, 26, 27

—

—

1

V

Referenced to GND

Input Pull-Up Current

—

5

—

µA

25

µA

Input Pull-Down Current

—

1

—

µA

Oscillator Output Current, High

—

1

—

mA

Oscillator Output Current, Low

—

1.5

—

mA

Buffered Oscillator Output

—

2

—

mA

Current, High

Buffered Oscillator Output

—

5

—

mA

Current, Low

Mode Input Pulse Width

60

—

—

nsec

HANDLING PRECAUTIONS: These devices are CMOS and must be handled correctly to prevent damage. Package

and store only in conductive foam, anti-static tubes, or other conducting material. Use proper anti-static handling

procedures. Do not connect in circuits under "power-on" conditions, as high transients may cause permanent

damage.

TC7109

TC7109A

12-BIT

ANALOG-TO-DIGITAL CONVERTERS
