IL393

Rev. 00

MAXIMUM RATINGS

Symbol

Parameter

Value

Unit

VCC

Power Supply Voltages

Single Supply

Split Supplies

±18

VIDR

Input Differential Voltage Range

VICR

Input Common Mode Voltage Range (1)

-0.3 to VCC

ISC

Output Short Circuit to Ground

Continuous

IIN

Input Current, per pin (2)

Junction Temperature

Plastic Packages

150

°C

Tstg

Storage Temperature

-65 to +150

°C

Lead Temperature, 1mm from Case for 10 Seconds

260

°C

Power Dissipation @TA=25°C

Plastic Package

Derate above 25

°C

570

5.7

mW/

°C

*Maximum Ratings are those values beyond which damage to the device may occur.

Functional operation should be restricted to the Recommended Operating Conditions.

Notes:

1. Split Power Supplies.

2. VIN<-0.3V. This input current will only exist when voltage at any of the input leads is driven negative.

RECOMMENDED OPERATING CONDITIONS

Symbol

Parameter

Min

Max

Unit

VCC

DC Supply Voltage

±2.5 or

5.0

±15 or

Operating Temperature, All Package Types

-40

+85

°C

This device contains protection circuitry to guard against damage due to high static voltages or electric fields.

However, precautions must be taken to avoid applications of any voltage higher than maximum rated voltages to this

high-impedance circuit. For proper operation, VIN and VOUT should be constrained to the range GND≤(VIN or

VOUT)≤VCC.

Unused inputs must always be tied to an appropriate logic voltage level (e.g., either GND or VCC). Unused outputs must

be left open.
