ADA4505-2/ADA4505-4
Rev. A | Page 11 of
20
80
70
60
50
40
30
20
10
0
10
100
1000
CAPACITANCE (pF)
TA = 25°C, unless otherwise noted.
80
70
60
50
40
30
20
10
0
10
100
1000
CAPACITANCE (pF)
VSY = 1.8V
VIN = 10mV p-p
RL = 100kΩ
VSY = 5V
VIN = 10mV p-p
RL = 100kΩ
OS+
OS–
OS+
OS–
Figure 34. Small Signal Overshoot vs. Load Capacitance
Figure 37. Small Signal Overshoot vs. Load Capacitance
T
TIME (200µs/DIV)
LOAD = 100kΩ || 100pF
VSY = 1.8V
1.490V p-p
Figure 35. Large Signal Transient Response
T
TIME (200µs/DIV)
LOAD = 100kΩ || 100pF
VSY = 1.8V
Figure 36. Small Signal Transient Response
T
LOAD = 100kΩ || 100pF
VSY = 5V
3.959V p-p
TIME (200µs/DIV)
Figure 38. Large Signal Transient Response
T
LOAD = 100kΩ || 100pF
VSY = 5V
TIME (200µs/DIV)
Figure 39. Small Signal Transient Response
