 2 / 5 page
background image
* Pulse test: tp
≤ 300µs δ < 2%.
Symbol
Test Conditions
Min.
Typ.
Max.
Unit
VBR
Tj = 25
°CIR = 10µA
TMMBAT47
20
V
Tj = 25
°CIR = 25µA
TMMBAT48
40
VF*
Tj = 25
°C
IF = 0.1mA
All Types
0.25
V
Tj = 25
°C
IF = 1mA
0.3
Tj = 25
°C
IF = 10mA
0.4
Tj = 25
°C
IF = 30mA
TMMBAT47
0.5
Tj = 25
°C
IF = 150mA
0.8
Tj = 25
°C
IF = 300mA
1
Tj = 25
°C
IF = 50mA
TMMBAT48
0.5
Tj = 25
°C
IF = 200mA
0.75
Tj = 25
°C
IF = 500mA
0.9
IR*
Tj = 25
°C
VR = 1.5V
All Types
1
µA
Tj = 60
°C
10
Tj = 25
°C
VR = 10V
TMMBAT47
4
Tj = 60
°C
20
Tj = 25
°C
VR = 20V
10
Tj = 60
°C
30
Tj = 25
°C
VR = 10V
TMMBAT48
2
Tj = 60
°C
15
Tj = 25
°C
VR = 20V
5
Tj = 60
°C
25
Tj = 25
°C
VR = 40V
25
Tj = 60
°C
50
STATIC CHARACTERISTICS
ELECTRICAL CHARACTERISTICS
Symbol
Test Conditions
Min.
Typ.
Max.
Unit
C
Tj = 25
°CVR = 0V
f = 1MHz
20
pF
Tj = 25
°CVR = 1V
12
trr
Tj = 25
°C
IF = 10mA
VR = 1V
irr = 1mA
RL = 100
Ω
10
ns
DYNAMIC CHARACTERISTICS
2/5
TMMBAT 47/TMMBAT 48
