Thick Film Resistor Networks, Dual-In-Line

Small Outline Molded Dip, 01, 03, 05 Schematics

www.vishay.com

For technical questions, contact: ff2aresistors@vishay.com

Document Number: 31506

32

Revision: 25-Aug-06

SOGC 01, 03, 05

Vishay Dale

FEATURES

• 0.110" [2.79 mm] maximum seated height

• Rugged, molded case construction

• 0.050" [1.27 mm] lead spacing

• Reduces total assembly costs

• Compatible with automatic surface mounting

equipment

• Uniform performance characteristics

• Meets EIA PDP 100, SOGN-0003 outline dimensions

• Available in tube pack or tape and reel pack

• Lead (Pb)-free version is RoHS compliant

Available

RoHS*

COMPLIANT

e1

* Tolerances in brackets available upon request.

• 100 milliohm maximum on zero ohm jumper

* Pb containing terminations are not RoHS compliant, exemptions may apply

STANDARD ELECTRICAL SPECIFICATIONS

GLOBAL

MODEL

SCHEMATIC

RESISTOR

CIRCUIT

W @ 70°C

PACKAGE

POWER

W @ 70°C

TOLERANCE

± %

RESISTANCE

RANGE

Ω

OPERATING

VOLTAGE

VDC

TEMPERATURE

COEFFICIENT

ppm/°C

SOGC16

01

0.1

1.6

2 (1, 5*)

10-1M0

50 max

100

03

0.19

1.6

2 (1, 5*)

10-1M0

50 max

100

05

0.1

1.6

2 (5*)

10-1M0

50 max

100

SOGC20

01

0.1

2.0

2 (1, 5*)

10-1M0

50 max

100

03

0.19

2.0

2 (1, 5*)

10-1M0

50 max

100

05

0.1

2.0

2 (5*)

10-1M0

50 max

100

GLOBAL

PIN COUNT

SCHEMATIC

RESISTANCE

TOLERANCE

PACKAGING

SPECIAL

MODEL

VALUE

CODE

SOGC

16

05 = Dual Terminator

3 digit Impedance

F = ± 1%

EJ= Lead Free,Tube

Blank = Standard

20

code, followed by

G = ± 2%

EA=

Tape & Reel

(Dash Number)

Alpha modifier

J= ± 5%

DC= Tin/Lead,Tube(up to 3 digits)

(see Impedance

RZ= Tin/Lead,Tape & Reel

From1-999 as

Codes table)

applicable

GLOBAL

PIN COUNT

SCHEMATIC

RESISTANCE

TOLERANCE

PACKAGING

SPECIAL

MODEL

VALUE

CODE

SOGC

16

01 = Bussed

R = Decimal

F = ± 1%

EJ= Lead Free,Tube

Blank = Standard

20

03 = Isolated

K = Thousand

G = ± 2%

EA=

Tape & Reel

(Dash Number)

00 = Special

M = Million

J= ± 5%

DC= Tin/Lead,Tube(up to 3 digits)

10R0 = 10

Ω

S = Special

RZ= Tin/Lead,Tape & Reel

From1-999 as

680K = 680 K

Ω

Z = 0

Ω Jumper

applicable

1M00 = 1.0 M

Ω

GLOBAL PART NUMBER INFORMATION

New Global Part Numbering: SOGC200310K0GDC (preferred part numbering format)

SO

G

C

2

0

03

1

0

K

0

G

D

C

Historical Part Number example: SOGC2003103G (will continue to be accepted)

SOGC

20

03

103

G

D02

HISTORICAL

PIN COUNT

SCHEMATIC

RESISTANCE

TOLERANCE

PACKAGING

MODEL

VALUE

CODE

SOGC

16

05

221

331

G

R61

HISTORICAL

PIN COUNT

SCHEMATIC

RESISTANCE

RESISTANCE

TOLERANCE

PACKAGING

MODEL

VALUE1

VALUE 2

CODE

New Global Part Numbering: SOGC1605131AGRZ (preferred part numbering format)

SO

G

C

1

6

05

1

3

1

A

G

R

Z

Historical Part Number example: SOGC1605221331G (will continue to be accepted)

Lead (Pb)-free,

Lead (Pb)-free,
