Section 26 Boundary Scan
Rev. 2.00 Sep. 24, 2008 Page 1205 of 1468
REJ09B0412-0200
Section 26 Boundary Scan
This LSI has boundary scan function, which is a serial I/O interface based on the JTAG (Joint Test
Action Group, IEEE Std.1149.1 and IEEE Standard Test Access Port and Boundary-Scan
Architecture).
26.1
Features
• Boundary scan valid single chip mode when the EMLE pin= 0 in MCU operating mode 3
• P62, P63, P64, P65, and WDTOVF are pins only for boundary scan when boundary scan is
valid
• Six test modes:
BYPASS mode
EXTEST mode
SAMPLE/PRELOAD mode
CLAMP mode
HIGHZ mode
IDCODE mode
