background image
2SC5543
Rev.2.00 Aug 10, 2005 page 2 of 7
Electrical Characteristics
(Ta = 25°C)
Item
Symbol
Min
Typ
Max
Unit
Test Conditions
Collector cutoff current
ICBO
—
—
10
µA
VCB = 15V , IE = 0
Collector cutoff current
ICEO
—
—
1
mA
VCE = 8V , RBE =
∞
Emitter cutoff current
IEBO
—
—
10
µA
VEB = 1.5V , IC = 0
DC current transfer ratio
hFE
85
—
170
VCE = 1V , IC = 5mA
Collector output capacitance
Cob
—
0.51
0.9
pF
VCB = 1V , IE = 0
f = 1MHz
Gain bandwidth product
fT
5.5
8.5
—
GHz
VCE = 1V , IC = 5mA
Power gain
PG
11
13.7
—
dB
VCE = 1V, IC = 5mA
f = 900MHz
Noise figure
NF
—
1.1
2.5
dB
VCE = 1V, IC = 5mA
f = 900MHz
