Page <1>

V1.0

22/09/20

Internal Sounder

Speaker

Newark.com/exclusive-brands

Farnell.com/exclusive-brands

Element14.com/exclusive-brands

Dimensions : Millimetres

Specifications

Max. Power

: 12W

Frequency Range

: 5kHz

Material

: Mylar

Diagram

Important Notice : This data sheet and its contents (the “Information”) belong to the members of the AVNET group of companies (the “Group”) or are licensed to it. No licence is granted for

the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change

without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness,

any error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make

any assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or

where the Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Group’s liability for death or personal injury resulting from its

negligence. pro - SIGNAL is the registered trademark of Premier Farnell Limited 2019.

Part Number Table

Description

Size (mm)

Part Number

Speaker, Mylar Cone, 8Ω, Square

87 × 87 × 35 BDM8760F-RX
