USP2DPF Folha de dados(HTML) 1 Page - Infinite Electronics International, Inc.

USP2DPF Datasheet HTML 1Page - Infinite Electronics International, Inc.

1 / 1 page

background image

2X, DISPLAY PORT

COUPLER, F/F

PIN 1

4X, 6-32 UNC-2B

THRU

68.1

2.68

3.23

82.0

70.10

2.760

55.88

2.200

1.10

27.9

PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE

USP-2DPF

1

A

A

PROJECTION

CATEGORY

7

DIMENSIONS ARE IN INCHES [mm]

CONFIGURATION DETAILS OF

01845

SCALE:

SIZE

CAD FILE:

DWG. NO.

A

SHEET

OF

REV.

DATE

APPROVALS

DRAWN BY

CHECKED BY

APPROVED BY

1

2

3

4

5

COLOR VARIATIONS

B

C

D

50 HIGH STREET

WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.

A

B

C

D

1

2

3

4

5

6

7

M.MARTINEZ

UNLESS OTHERWISE SPECIFIED,

1

8

USP-2DPF.SLDDRW

7/25/17

REVISIONS

DESCRIPTION

MAY OCCUR

7/25/17

DATE

7/25/17

INITIAL RELEASE

M.MARTINEZ

D.FRISIELLO

D.FRISIELLO

6

APPROVED

8

THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE

MAY VARY

NONE

FSCM NO.

7/25/17

43321

RACK/ENCLOSURES

REV

NORTH ANDOVER, MA

UNDIMENSIONED FEATURES

USP SUB-PNL W/2 DP F-F CPLR

PRODUCT DESCRIPTION

A

OVERALL CABLE LENGTH TOLERANCE:

≤12 [305] = +1 [25] / -0

>12 [305] ≤60 [1524] = +2 [51] / -0

>60 [1524] ≤120 [3048] = +4 [102] / -0

>120 [3048] ≤300 [7620] = +6 [152] / -0

>300 [7620] = +5% / -0%

ALL OTHER DIMENSIONAL TOLERANCES:

.X = ± .2 [5.08]

.XX = ± .02 [.51]

.XXX = ±.005 [.13]

2X, 4-40 UNC-2B

HEX STANDOFF

1.18

30.0

.06

1.5

NOTES:

1. PANEL MATERIAL: .06 [1.5] THK COLD ROLLED STEEL.

2. PANEL FINISH: FLAT BLACK POWDER COAT.

3. KIT CONTAINS 4, #6-32 UNC SCREWS.

4. COMPONENT SHALL BE INDIVIDUALLY PACKAGED IN

ACCORDANCE WITH L-COM SPECIFICATION PS-0031.

REGULATORY COMPLIANCE:

CE2011/65/EU(RoHS DIRECTIVE)
