136-174 MHz, 3.5 dBi Gain, Omni-directional Antenna with

Magnetic NMO Mount, Reverse Polarity-TNC Plug Connector

LCANMOB1006-RTP

Radome Material

Stainless Steel

Size

Length

54.74 in [139.04 cm]

Width

3 in [76.2 mm]

Height

3 in [76.2 mm]

Weight

1.46 lbs [662.24 g]

Environmental Specifications

Compliance Certifications (see product page for current document)

Plotted and Other Data

Notes:

1: Loosen Screw, Sperate Whip and Base.

2: Find whip length of correct frequency according to cuting chart.

3: Measure the length of the steel whip and cut it from bottom side

without cap.

4: Re-fix the steel whip and the base with screws.

136-174 MHz, 3.5 dBi Gain, Omni-directional Antenna with Magnetic NMO Mount, Reverse Polarity-TNC Plug Connector from L-com

has same day shipment for domestic and International orders. Our portfolio includes coaxial cable assemblies, connectors, adapters

and custom products as well as lightning and surge protectors, NEMA rated enclosures, and an RF product line which includes

antennas, amplifiers, passive, and active components.
