Part numbering

M95512-W, M95512-R

36/39

Part numbering

Ordering information related to the M95512-W and M95512-R identified with the process letter "A".

For a list of available options (speed, package, etc.) or for further information on any aspect

of this device, please contact your nearest ST Sales Office.

The category of second Level Interconnect is marked on the package and on the inner box

label, in compliance with JEDEC Standard JESD97. The maximum ratings related to

soldering conditions are also marked on the inner box label.

Table 17.

Ordering information scheme(1)

Example:

M95512

–

W MN

Device type

M95 = SPI serial access EEPROM

Device function

512 = 512 Kbit (65536 × 8)

Operating voltage

W = VCC = 2.5 V to 5.5 V

R = VCC = 1.8 V to 5.5 V

Package

MN = SO8 (150 mil width)

DW = TSSOP8 (169 mil width)

Device grade

6 = Industrial temperature range, –40 to 85 °C.

Device tested with standard test flow

Option

blank = Standard Packing

T = Tape and Reel Packing

Plating technology

P or G = ECOPACK® (RoHS compliant)
