Silicon NPN Power Transistor

2SC3668

www.iscsemi.com

1

DESCRIPTION

· Collector-Emitter Breakdown Voltage

-V(BR)CEO= 50V(Min)

· Collector-Emitter Saturation Voltage

-VCE(sat): 0.5V(Max) @IC= 1.0A

APPLICATIONS

· Power Amplifier Applications

· Power Switching Applications

ABSOLUTE MAXIMUM RATINGS(Ta=25℃)

SYMBOL

PARAMETER

VALUE

UNIT

VCBO

Collector-Base Voltage

50

V

VCEO

Collector-Emitter Voltage

50

V

VEBO

Emitter-Base Voltage

5

V

IC

Collector Current-Continuous

2

A

IB

Base Current

0.5

A

PC

Collector Power Dissipation

1

W

TJ

Junction Temperature

150

℃

Tstg

Storage Temperature Range

-55~150

℃
