Data Sheet
SSM3582A
Rev. A | Page 13 of 58
Pin No.
Mnemonic
Type1
Description
28
DVDD
PWR
Digital Supply 1.8 V Regulator Output/External 1.8 V Input.
29
PGND
PWR
Left Channel Power Stage Ground.
30
PGND
PWR
Left Channel Power Stage Ground.
31
BSTL−
AIN
Bootstrap Input, Left Channel Inverting.
32
OUTL−
AOUT
Left Channel Inverting Output.
33
OUTL−
AOUT
Left Channel Inverting Output.
34
PVDD
PWR
Left Channel Power Stage Supply.
35
PVDD
PWR
Left Channel Power Stage Supply.
36
PVDD
PWR
Left Channel Power Stage Supply.
37
PVDD
PWR
Left Channel Power Stage Supply.
38
OUTL+
AOUT
Left Channel Noninverting Output.
39
OUTL+
AOUT
Left Channel Noninverting Output.
40
BSTL+
AIN
Bootstrap Input, Left Channel Noninverting.
EPAD
Exposed Pad. Use multiple vias to connect the exposed pad to the ground plane on the PCB.
1
PWR is power supply or ground pin, AIN is analog input, DIN is digital input, DIO is digital input/output, and AOUT is analog output.
