12 / 49 page

FT201X USB I2C SLAVE IC Datasheet

Version 1.4

Document No.: FT_000627 Clearance No.: FTDI# 264

CBUS

Signal

Option

Available On CBUS Pin

Description

VBUS Sense

CBUS0, CBUS1, CBUS2, CBUS3, CBUS4,

CBUS5

Input to detect when VBUS is present.

Time Stamp

CBUS0, CBUS1, CBUS2, CBUS3, CBUS4,

CBUS5

Toggle signal which changes state each time a USB SOF is

received

Keep_Awake#

CBUS0, CBUS1, CBUS2, CBUS3, CBUS4,

CBUS5

Prevents the device from entering suspend state when

unplugged. May be used if programming the MTP memory

over I2C

Table 3.7 CBUS Configuration Control

*When in USB suspend mode the outputs clocks are also suspended.
