Product Information • SCL-RHYTHM • M.2 NVMe & Quad M12 Gigabit Ethernet
M.2 Module Fixation (Picture Similar)
PCIe x4 M.2
2230
2260
2280
2242
M
M.2
PCIe x4
NVMe
HSE1
HSE2
M.2 Connector
The SCL-RHYTHM is provided with an M.2 NVMe module host connector (M-key). After inserted, the
M.2 module must be locked manually by a screw, in order to withstand shock and vibration.
© EKF
-8-
ekf.com
