 2 / 5 page
background image
•
Built-in RC Oscillation
•
Four changeable Slave Addresses
Pinout
Name
Function
SDA
Date Line
SCL
Control Line
GND
Positive
VCC
Negative
Communication Description
Address Change
There are two solder pads of data bits A0 and A1 on the back of the LED display
(disconnect: 0/connect: 1). The four slave addresses can be realized by the combination
of A0 and A1, shown as below.
The address format of LED controller:
