Part Number: 38 Series

General Purpose - 1 Form A / 2 Form A - PhotoDMOS Relays

Product Data Sheet

SCHEMATIC

ORDERING INFORMATION

FEATURES


Phone: (1) 973 777 6900

www.comus-intl.com

Fax: (1) 973 777 8405

As part of the company policy of continued product improvement, specifications may change without notice. Our sales office will be pleased to help you with the latest information on this product range and

the details of our full design and manufacturing service. All products are supplied to our standard conditions of sale unless otherwise agreed in writing.

An ISO 9001 Certified Company

Belgium: + 32 (0)12 390400 - Comus Europe Ltd (Assemtech) UK: +44 (0) 1255 862236 - Germany: +49 (0)911 923 15 943 - Netherlands: +31(0)45 54 39 345 - India: +(91) (44) 43219090

©2016 Copyright Comus International, 454 Allwood Road, Clifton NJ 07012, USA

Relays

•

PhotoDMOS Relays

• 600 Volt, 80 mA

• On-Resistance: 40 Ω (typical)

• I/O Breakdown Voltage: SOP 1500 Vrms Min.

DIP / SMD 3750 Vrms Min.

• Optional High I/O BV: SOP 3750 Vrms Min.

DIP / SMD 5000 Vrms Min.

• Max LED Current 3.0 mA

• Low Off-State Leakage Current 1.0 μ A Max

• UL File E344988

1: Anode

2: Cathode

3: NC

4, 6: Drain

5: Source

1: Anode

2: Cathode

3, 4: Drain

1, 3: Anode

2, 4: Cathode

5, 6, 7, 8: Drain

(LED)

(LED)

(MOS FET)

(MOS FET)

(LED)

(LED)

(MOS FET)

(LED)

(LED)

(MOS FET)

®

SOP4

SOP8

SMD4

DIP4

DIP6

4.4

4.4

6.4

6.4

6.4

6.4

6.4

2.0

2.0

3.4

3.4

3.4

3.4

3.4

4.3

9.4

4.7

8.8

4.7

8.8

9.8

3.4

6.4

9.8

SMD6

SMD8

DIP8

(+)

(-)

(+)

(-) (+) (-)

(+) (-)

4

3

6 5 4

1 2 3

1

2

3

4

8

7

6

5

1

2

Drawings not to scale. All dimensions in mm nominal. Pitch: 2.54 mm

Part Number Example: XX38X-XX

AC38F-R1 = Series 38, 2 Form A, 8 Pin, SMD with tape and reel

packaging

AB38(F)(S)

AC38(F)(S)

AA38(F)

600 VOLTS

Rev: 0 - Date: June/16/2016 - Signature: BR

38

AB = 4 pin

AA = 6 pin

AC = 8 pin

Body Style Series Options

F = SMD

S = SOP

R1 = Tape & Reel (SMD / SOP Only)

H = 5KV I/O BV (DIP / SMD Only)

H = 3.75KV I/O BV (SOP Only)
