Relays

ITEM

SYMBOL

VALUE

OUTLINE PACKAGE

SOP 4/8

DIP 4/8

SMD 4/8

DIP 6

SMD 6

1CH

2CH

1CH

2CH

1CH

Input

Continuos LED Current

IF

50 mA

Peak LED Current (f=100 Hz, duty=1%)

IFP

500 mA

LED Reverse Voltage

VR

5 V

Input Power Dissipation

PIn

75 mW

Output

Load Voltage

VL

350 V (AC peak or DC)

Load Current (mA)

IL

120

100

130

110

130

Peak Load Current (1 ms, 1 shot) (mA)

IPeak

600

600

600

600

600

Output Power Dissipation (mW)

POut

300

450

450

600

450

Total Power Dissipation (mW)

PT

350

500

500

650

500

I/O Breakdown Voltage (Vrms)

VI/O

1500

1500

3750

3750

3750

Operating Temperature

TOpr

-40˚ +85˚C

Storage Temperature

TStg

-40˚ +100˚C

ITEM

SYMBOL

MIN

TYP

MAX

UNITS

CONDITIONS

Input

LED Forward Voltage

VF

1.0

1.17

1.5

V

IF = 10mA

Operation LED Current

IF On

0.8

3.0

mA

Recovery LED Voltage

VF Off

0.5

1.0

V

Output

On-Resistance Drain to Drain

ROn

17

24

Ω

IF = 5mA

IL = Rating Time to flow is

within 1 sec.

Off-State Leakage Current

ILeak

1.0

μA

VL=350V

Output Capacitance

COut

55

pF

VL=0V, f=1MHz

Transmission

Turn-On Time

TOn

0.25

0.5

ms

IF = 5mA

IL = Rating

(for SOP type)

Turn-Off Time

TOff

0.05

0.2

ms

Turn-On Time

TOn

0.2

1.0

ms

IF = 10mA

IL = Rating

(for DIP/SMD type)

Turn-Off Time

TOff

0.05

0.5

ms

Coupled

I/O Insulation Resistance

RI/O

109

Ω

I/O Capacitance

CI/O

1.3

pF

f = 1MHz

ABSOLUTE MAXIMUM RATINGS (Ambient Temperature: 25˚C)

ELECTRICAL SPECIFICATIONS (Ambient Temperature: 25˚C)

Part Number: 31 Series

General Purpose - 1 Form A / 2 Form A - PhotoDMOS Relays

Product Data Sheet

350 VOLTS
