IP113A LF
Preliminary Data Sheet
7/22
April 9, 2007
Copyright © 2004, IC Plus Corp.
IP113A LF-DS-R08
1.
PIN Description (continued)
Pin no.
Label
Type
Description
MC operation mode
29
X_EN
O/IPH
IEEE 802.3X enable on TP port and fiber port
1: enable (default),
0: disable
It is an input pin during reset period. The default value is
latched at the end of reset.
After reset, it becomes an output pin for testing.
It should be connected to GND through a 1k ohm resister
to set 0.
24
TP_FORCE
O/IPL
Local TP port auto negotiation enable
1: TP port supports auto-negotiation with limited capability
defined in SPEED_MODE and DUPLEX_MODE.
0: TP port supports auto-negotiation with 10M/100M, full/
half capability (default)
The default value may be updated by either programming
EEPROM register 3.5 or MII register 20.13.
It is an input pin during reset period. The default value is
latched at the end of reset.
After reset, it becomes an output pin for testing.
It should be connected to VCC through a 1k ohm resister
to set 1.
38
SPEED_MODE
IPH
Local TP port speed
1: TP port has the 100Mb speed ability
0: TP port has the 10Mb speed ability only
It is valid only if TP_FORCE is enabled.
30
DUPLEX_MODE
IPH
Local TP port duplex
1: TP port has the Full duplex ability
0: TP port has the Half duplex ability only
It is valid only if TP_FORCE is enabled.
36
FX_FULL
IPH
Set the duplex of fiber port
1: full duplex (default)
0: half duplex
