 14 / 22 page
background image
IP113A LF
Preliminary Data Sheet
FX port disconnected
IP113A
LF
IP113A
LF
UTP
UT
Fiber
P
Switch1
Switch2
LED
SW1
LED_TP_LINK1 LED_FX_LINK1
LED
SW2
local
remote
LED_FX_LINK2 LED_TP_LINK2
Link LED on
SW1
LED_TP_LINK1 LED_FX_LINK1 LED_FX_LINK2 LED_TP_LINK2
Link LED on
SW2
Off
Off
Off
Off
Off
Off
LED diagnostic functions for fault indication
LED_TP_LINK
LED_FX_LINK
LED_FX_SD
LED_FX_FEF_DET
Status
On
On
On
Off
Link ok
Flash
Flash
On
Off
Link ok & activity
Off
Off
On
Off
Remote TP link off
Off
Off
Off
Off
Fiber RX off, Fiber TX/ RX off
Off
Off
On
Flash
Fiber TX off
Note
Flash: flash, period 100 ms
Link fault pass through is enabled.
April 9, 2007
14/22
Copyright © 2004, IC Plus Corp.
IP113A LF-DS-R08
