Product Type

Power Chokes

3626

Features

Board Area from 7.5mm x 7.5mm

Values 10μH to 5,000μH

Current up to 4 Amps

Less than 4mm Height

2 Package Sizes

Product Type

Power Chokes

Power Chokes

Power Chokes

Power Chokes

Power Chokes

3621

3622

3623

3624

3625

Features

Board Area from 3mm x 2.8mm Board Area from 6.6mm x 4.5mm Board Area from 22mm x 15mm Board Area from 3.2mm x 1.6mm Board Area from 6mm x 6mm

Values 1μH to 15,000μH

Values 1μH to 10,000 μH

Values 0.8μH to 1,000μH

Values 0.12μH to 3,300μH

Values 1.5μH to 1,000μH

Current up to 9.5 Amps

Current up to 10 Amps

Current up to 16 Amps

Current up to 9 Amps

Current up to 7.2 Amps

Only 1.5mm Height

Less than 3mm Height

Less than 7mm Height

Less than 2mm Height

Less than 3mm Height

12 Package Styles

4 Package Sizes

2 Package Sizes

8 Package Sizes

3 Package Sizes

Product Type

Insulated

Leaded Axial

Leaded Radial

Moulded

SC 10 / 20 / 30

SC

SC

MSC

Features

0402 to 1812 and Arrays

4 Package SIzes

4 Package SIzes

2 Case Sizes

5R to 2K ohms impedance

Suited to Power Circuits

Suited to Power Circuits

0.1μH to 10mH Value (E12 Grid)

DC Current up to 6 Amps

Wide Value Range

Wide Value Range

DC Current up to 1.79 Amps

HS Signal Line, Digital Sound,

E12 Series Values

E12 Series Values

5% or 10% Tolerance

High Current, High Loss, etc

DC Current to 1.7A

DC Current to 5.6A

Dielectric Strength up to 1KV

11

Specifications subject to change.

Dimensions are shown in mm

for reference purposes only.

Catalogue No. 1309350

August 2007

tycoelectronics.com

passives.tycoelectronics.com

Passive Components

Inductive Products, Power, Surface Mount - Unshielded

Inductive Products, Leaded - Unshielded
