background image
SIGNAL LIGHTS
18
AVG
B – 012 – R
Lens Colors
R
Red
Y
Yellow
G
Green
B
Blue
Power Supply
01
DC 1V
02
DC 4V
10
AC 110V
20
AC 0V
Light Style
Rotating Light
B
Rotating Light
with Buzzer
Order Information
Optional Orders
Specifications
Dimensions
AVG Ø135mmRotatingBeaconswithBuzzer
Ø15
-M6 Bolt
Model
AVG
AVGB
Bulb Type
Incandescent
Power Supply
1VDC, 4VDC, 110VAC, 0VAC
Current
Draw
&
Wattage
1VDC
.08A, 5W
4VDC
1.04A, 5W
110VAC
0.A, 5W
0VAC
0.11A, 5W
Sound Level
—
80 dB
Rotation Rate
150 times/minute
FUSE
External
Contacts
Power Supply
White
Black
External
Contacts
White
Black
Brown
POWER
SUPPLY
110V
AC
0V
AC
FUSE
unit: mm
Stud Mount Hole Layout
MAM-DS7
Wall Mount Brackets
DC 12V & DC 24V
AVG-01-□ AVGB-01-□
AVG-02-□ AVGB-02-□
AC 110V & AC 220V
AVG-10-□ AVGB-10-□
AVG-20-□ AVGB-20-□
Wiring Diagram
Incandescent type
Red, Yellow, Green and Blue lens available
Smooth lens
Large rotating reflector
Long life
Stud mounted
Optional Wall Mounting Bracket (MAM-DS27) available
Buzzer (80dB) model available
•
•
•
•
•
•
•
•
Replacement Parts
Bulb
MAB-T15-D-012-25
1V DC, 5 Watt
MAB-T15-D-024-25
4V DC, 5 Watt
MAB-T15-D-130-25
110V AC, 5 Watt
MAB-T15-D-240-25
0V AC, 5 Watt
Lens
LENS-AVG-(□)
Smooth Lens for Rotating Lights
(□): indicates color of Lens; R, Y, G or B
NOTE: See Page 14 for Dimensions.
