SRP0612F Series – Shielded Power Inductors

Soldering Profile

Profile Feature

Pb Free Assembly

Preheat

- Temperature Min� (Tsmin)

- Temperature Max� (Tsmax)

- Time(ts) from Tsmin to Tsmax

150 °C

200 °C

60-120 seconds

Ramp-up Rate (TL to Tp)

3 °C/second max�

Liquidous temperature (TL)

Time (tL) maintained above TL

217 °C

60-150 seconds

Peak package body temperature (Tp)

260 °C

Time within 5 °C of Actual Peak Temperature

(tp)

<30 seconds

Ramp-Down Rate (Tp to TL)

6 °C/second max�

Time 25 °C to Peak Temperature

8 minutes max�

25

260

Time (Seconds)

REFLOW TIMES: 3 TIMES MAX.

PREHEAT AREA

MAX. RAMP UP RATE = 3 °C/SEC.

MAX. RAMP DOWN RATE = 6 °C/SEC.

Time 25 °C to Peak

8 Minutes Max.

TC -5 °C

200 °C

60~150

Sec.

217

150°C

60~120

Sec.

20~30 Sec.

Inductance vs. IDC

1.00

0.80

0.60

0.40

0.20

0

0

3.4

6.8

10.2

13.6

17.0

DC Current (A)

100

80

60

40

20

0

2.00

1.60

1.20

0.80

0.40

0

0

2.2

4.4

6.6

8.8

11.0

DC Current (A)

100

80

60

40

20

0

SRP0612F-1R5M

3.50

2.80

2.10

1.40

0.70

0

0

2.0

4.0

6.0

8.0

10.0

DC Current (A)

100

80

60

40

20

0

SRP0612F-2R2M

5.00

4.00

3.00

2.00

1.00

0

0

1.8

3.6

5.4

7.2

9.0

DC Current (A)

100

80

60

40

20

0

SRP0612F-3R3M

7.00

5.60

4.20

2.80

1.40

0

0

1.6

3.2

4.8

6.4

8.0

DC Current (A)

100

80

60

40

20

0

SRP0612F-4R7M

10.00

8.00

6.00

4.00

2.00

0

0

1.1

2.2

3.3

4.4

5.5

DC Current (A)

100

80

60

40

20

0

SRP0612F-6R8M

15.00

12.00

9.00

6.00

3.00

0

0

0.9

1.8

2.7

3.6

4.5

DC Current (A)

100

80

60

40

20

0

SRP0612F-100M

SRP0612F-R68M

0.70

0.56

0.42

0.28

0.14

0

0

4.0

8.0

12.0

16.0

20.0

DC Current (A)

100

80

60

40

20

0

SRP0612F-R47M

1.50

1.20

0.90

0.60

0.30

0

0

2.8

5.6

8.4

11.2

14.0

DC Current (A)

100

80

60

40

20

0

SRP0612F-1R0M
