1 / 1 page  MAY OCCUR A B C D COLOR VARIATIONS CONFIGURATION DETAILS OF 01845 SCALE: SIZE CAD FILE: DWG. NO. A SHEET OF REV. DATE APPROVALS DRAWN BY CHECKED BY APPROVED BY 1 2 3 4 5 6 7 8 NORTH ANDOVER, MA 45 BEECHWOOD DRIVE WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED. A B C D 1 2 3 4 5 6 7 8 CA-RSPNMB A CA-RSPNMB.SLDDRW 11 REVISIONS DESCRIPTION APPROVED REV DATE CATEGORY PRODUCT DESCRIPTION DIMENSIONS ARE IN INCHES [mm] PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE MAY VARY NONE FSCM NO. 43321 PROJECTION UNLESS OTHERWISE SPECIFIED, UNDIMENSIONED FEATURES OVERALL CABLE LENGTH TOLERANCE: ≤12 [305] = +1 [25] / -0 >12 [305] ≤60 [1524] = +2 [51] / -0 >60 [1524] ≤120 [3048] = +4 [102] / -0 >120 [3048] ≤300 [7620] = +6 [152] / -0 >300 [7620] = +5% / -0% ALL OTHER DIMENSIONAL TOLERANCES: .X = ± .2 .XX = ± .02 .XXX = ±.005 RP-SMA Plug To N-Male Assembly w/Heatshrink 02/11/10 2/11/10 B.Puchaski A M.Audas M.Audas B.Puchaski 02/11/10 02/11/10 Initial Release Fabrication: White CA-195RW Series COAXIAL (1X) CA-195RW/50Ω COAXIAL CABLE-WHITE CA-RSPNMBXXX N STRAIGHT MALE CABLE# & LENGTH CA-RSPNMBNXX CA-RSPNMBMXX WHERE XXX = LENGTH IN FEET WHERE NXX = LENGTH IN INCHES WHERE MXX = LENGTH IN METERS WHERE XMX = LENGTH IN DECIMEL METERS CA-RSPNMBXMX CA-RSPNMB010 (10 FEET) CA-RSPNMBN16 (16 INCHES) CA-RSPNMBM07 (7 METERS) CA-RSPNMB3M5 (3.5 METERS) EXAMPLES OF PART# USED LENGTH CODE CHART LENGTH SYMBOL CRIMP CONNECTOR L-COM SPECIFICATION PS-0031 6. CENTER PIN OF CONNECTORS TO BE SOLDERED OR CRIMPED ONTO CABLE INNER CONDUCTOR NOTES: 1. CABLE ASSEMBLY SHALL BE TESTED FOR CONTINUITY 2. CABLE ASSEMBLY SHALL RECIEVE INSERTION LOSS TEST#TP-00027 3. CABLE ASSEMBLY SHALL WITHSTAND PULL TEST OF 40lbs WITHOUT ANY SEPERATION OR ELECTRICAL FAILURE 4. CABLE SHALL BE RoHS COMPLIANT 5. CABLE ASSEMBLY SHALL BE INDIVIDUALLY PACKAGED IN ACCORDANCE WITH RP-SMA STRAIGHT PLUG CRIMP CONNECTOR (REF LENGTH CODE CHART) -LENGTH- 1"(±.04)[25.4mm(±1.0)] (2X) WHITE HEATSHRINK |
