background image
RPM7236-R series
Photo Link Module
Rev.C
1/6
IR Receiver Module
RPM7236-R series
RPM7236-R series are remote control receiver module. Small-sized, light-weight, and low voltage operated (from 2.7V)
modules have been achieved by using resin mold.
Center frequency
36.0kHz
Applications
All household electric appliances such as TV, DVD, air conditioner and audio equipment
Features
1) Low voltage operation. (VCC=2.7 to 3.6V)
2) Low current consumption. (ICC=0.3mA, VCC=3V)
3) Superior anti VCC noise characteristics.
4) 5 types of holders available to each set.
RPM7236-R series
SIDE VIEW
TOP VIEW
RSIP-A3 (H13)
Height of lens
15.0mm
RSIP-A3 (H9)
12.0mm
∗RPM7236-H9R
∗Under development
RSIP-A3 (H8)
7.2mm
∗RPM7236-H8R
∗RPM7236-H13R
RSIP-A3 (H5)
9.6mm
RPM7236-H5R
RSIP-A3 (H4)
15.9mm
RPM7236-H4R
Products No.
Absolute maximum ratings (Ta=25
°C)
Parameter
Symbol
Limits
Unit
Supply voltage
VCC
6.3
−30 to +100
2.0
V
Storage temperature
Output current
Tstg
IO
°C
−10 to +75
Operating temperature
Topr
°C
mA
Recommended operating conditions (Ta=25
°C)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Supply voltage
VCC
3.0
V
2.7
3.6
