background image
PowerPC 440SP Embedded Processor
54
AMCC Proprietary
Revision 1.23 - Sept 26, 2006
Data Sheet
Signal Description
The PPC440SP embedded controller is packaged in a 783-ball flip-chip plastic ball grid array (FC-PBGA). The
following table describes the package level pinout.
In the table “Signal Functional Description” on page 56, each I/O signal is listed along with a short description of its
function. Active-low signals (for example, RAS) are marked with an overline. Please see “Signals Listed
Alphabetically” on page 17 for the pin (ball) number to which each signal is assigned.
Table 5. Pin Summary
Group
No. of Pins
Signal pins, non-multiplexed
496
Signal pins, multiplexed
32
Total Signal Pins
528
AxVDD
2
APxVDD
3
AxGND
5
OVDD (3.3V I/Os)
15
PxVDD (3.3V-1.5V PCI)
31
SVDD G(2.5-1.8V SDRAM)
10
VDD (1.5V Logic)
47
GND
92
Total Power Pins
205
Reserved
50
Total Pins
783
