ORDERING GUIDE

Table 6. Ordering Guide

MODEL1

TEMPERATURE

RANGE

PACKAGE

DESCRIPTION

PACKING

QUANTITY

PACKAGE

OPTION

MARKING

CODE

ADPL44002ACPZN2.5-R7

-40°C to +125°C

6-Lead LFCSP

(2mm x 2mm w/EP)

Reel, 3000

CP-6-3

LXM

ADPL44002ACPZN3.3-R7

-40°C to +125°C

6-Lead LFCSP

(2mm x 2mm w/EP)

Reel, 3000

CP-6-3

LXN

ADPL44002ACPZN5.0-R7

-40°C to +125°C

6-Lead LFCSP

(2mm x 2mm w/EP)

Reel, 3000

CP-6-3

LXP

ADPL44002ACPZN-R7

-40°C to +125°C

6-Lead LFCSP

(2mm x 2mm w/EP)

Reel, 3000

CP-6-3

LXQ

ADPL44002AUJZ1.8-R7

-40°C to +125°C

5-Lead TSOT

Reel, 3000

UJ-5

LXR

ADPL44002AUJZ2.5-R7

-40°C to +125°C

5-Lead TSOT

Reel, 3000

UJ-5

LXM

ADPL44002AUJZ3.3-R7

-40°C to +125°C

5-Lead TSOT

Reel, 3000

UJ-5

LXN

ADPL44002AUJZ5.0-R7

-40°C to +125°C

5-Lead TSOT

Reel, 3000

UJ-5

LXP

ADPL44002AUJZ-R7

-40°C to +125°C

5-Lead TSOT

Reel, 3000

UJ-5

LXQ

1

Z = RoHS Compliant Part

Table 7. Output Voltage Options

MODEL

OUTPUT VOLTAGE (V)1

ADPL44002ACPZN2.5-R7

2.5

ADPL44002ACPZN3.3-R7

3.3

ADPL44002ACPZN5.0-R7

5.0

ADPL44002ACPZN-R7

Adjustable (1.2 V)

ADPL44002AUJZ1.8-R7

1.8

ADPL44002AUJZ2.5-R7

2.5

ADPL44002AUJZ3.3-R7

3.3

ADPL44002AUJZ5.0-R7

5.0

ADPL44002AUJZ-R7

Adjustable (1.2 V)

1

For additional voltage options, contact a local Analog Devices, Inc., sales or distribution representative.

Table 8. Evaluation Boards

MODEL1, 2

PACKAGE DESCRIPTION

EVAL-ADPL44002CP-AZ

LFCSP Evaluation Board

EVAL-ADPL44002UJ-AZ

TSOT Evaluation Board

1

Z = RoHS Compliant Part

2

The evaluation boards are preconfigured with an adjustable ADPL44002.
