5

Environmental and certifications

5.1

Environmental specifications

Table 5. Operating condition

Parameter

Min.

Typ.

Max.

Unit

Extended operating temperature

-40

+85

°C

Note:

In the extended operating temperature, the module remains fully functional during and after environmental

exposure.

Table 6. Storage condition

Parameter

Min.

Typ.

Max.

Unit

Storage temperature

-40

+85

°C

Note:

The module is delivered in tape and reel carriers and must be stored in sealed, moisture barrier, antistatic bags.

Note:

The module is not powered.

5.2

Regulatory

The ST87M01 is designed to comply with the directives and standards listed in the following sections.

5.2.1

RED

RED certification covers the bands FDD 1, FDD 3, FDD 8, FDD 20, and FDD 28.

Table 7. RED information

EMC

[Radio]

EMC testing according to:

•

EN 301 489-1 V2.2.3: common technical requirements

•

EN 301 489-19 V2.2.1: GNSS

•

EN 301 489-52 V1.2.1: LTE NB-IoT

RF

[NB-IoT]

LTE NB-IoT RF conducted testing according to EN 301 908-13 V13.2.1

RF

[NB-IoT]

LTE NB-IoT Radiated Spurious Emissions (RSE) testing according to EN 301 908-1 V15.1.1

RF

[NB-IoT]

LTE NB-IoT RF conducted assessment according to EN 301 908-13 V13.2.1

RF

[GNSS]

GNSS RF testing according to EN 303 413 V1.2.1 for the following constellations

•

GPS: L1

MPE

RF exposure report according to EN 62311:2020 standard

Safety

Electrical safety testing according to EN 62368-1:2014/AC:2015

The full text of the EU declaration of conformity is available online at the following address:

https://www.st.com/

5.2.2

GCF

GCF certification covers the bands FDD 1, FDD 3, FDD 5, FDD 8, FDD 20, and FDD 28.

ST87M01

Environmental and certifications

DS14679 - Rev 1

page 9/20
