Data Sheet

ADA4530-1

SPECIFICATIONS

analog.com

Rev. C | 4 of 52

Table 1. (Continued)

Parameter1

Symbol

Test Conditions/Comments

Min

Typ

Max

Unit

Unity-Gain Crossover

UGC

VIN = 10 mV rms, RL = 10 kΩ, CL = 10 pF, AVO = 1

2

MHz

−3 dB Closed-Loop Bandwidth

f−3dB

VIN=10 mV rms, RL = 10 kΩ, CL = 10 pF, AV = 1

6

MHz

Phase Margin

ΦM

VIN = 10 mV rms, RL = 10 kΩ, CL = 10 pF, AVO = 1

62

Degrees

Settling Time to 0.1%

tS

VIN = 0.5 V step, RL = 10 kΩ, CL= 10 pF, AV = −1

5

µs

EMI Rejection Ratio of +IN

EMIRR

VIN = 100 mV peak, f = 400 MHz

50

dB

VIN = 100 mV peak, f = 900 MHz

60

dB

VIN = 100 mV peak, f = 1800 MHz

80

dB

VIN = 100 mV peak, f = 2400 MHz

90

dB

NOISE PERFORMANCE

Peak-to-Peak Voltage Noise

eN p-p

f = 0.1 Hz to 10 Hz

4

µV p-p

Voltage Noise Density

eN

f = 10 Hz

80

nV/√Hz

f = 1 kHz

16

nV/√Hz

f = 10 kHz

14

nV/√Hz

Current Noise Density

IN

f = 0.1 Hz

0.07

fA/√Hz

Total Harmonic Distortion + Noise

THD + N

AV = 1, f = 1 kHz, VIN = 0.5 V rms

Bandwidth = 90 kHz

0.003

%

Bandwidth = 500 kHz

0.0045

%

GUARD BUFFER

Guard Offset Voltage2, 4, 5

VGOS

VCM = 1.5 V to 3 V

15

100

µV

VCM = 1.5 V to 3 V, 0°C < TA < 125°C

120

µV

VCM = 1.5 V to 3 V, −40°C < TA < 0°C

250

µV

VCM = 0.1 V to 3 V

150

µV

Guard Offset Voltage Drift2, 4

ΔVGOS/ΔT

0°C < TA < +125°C

0.18

1

µV/°C

−40°C < TA < 0°C

1.4

7

µV/°C

Output Impedance

ZGOUT

1

kΩ

Output Voltage Range

VGOS < 150 µV

0.1

3

V

−3 dB Bandwidth

f−3dBGUARD

VIN = 10 mV rms, CL = 10 pF

5.5

MHz

1 These specifications represent the performance for 5 V ± 10% power supplies. All specifications are measured at the worst case 4.5 V supply voltage.

2 The maximum specifications at −40°C < TA < +85°C and −40°C < TA < 0°C are guaranteed from characterization.

3 RH is relative humidity (see the Humidity Effects section for more information).

4 The typical specifications are equal to the average plus the standard deviation of the distribution from characterization.

5 The guard offset voltage is the voltage difference between the guard output and the noninverting input.

10 V NOMINAL ELECTRICAL CHARACTERISTICS

VSY = 10 V, VCM = VSY/2, TA = 25°C, unless otherwise noted. Typical specifications are equal to the average of the distribution from

characterization, unless otherwise noted. Minimum and maximum specifications are tested in production, unless otherwise noted.

Table 2.

Parameter1

Symbol

Test Conditions/Comments

Min

Typ

Max

Unit

INPUT CHARACTERISTICS

Input Bias Current2, 3

IB

RH < 50%

<1

±20

fA

−40°C < TA < +85°C, RH < 50%

±20

fA

−40°C < TA < +125°C, RH < 50%

±250

fA

Input Offset Current3

IOS

RH < 50%

<1

±20

fA

−40°C < TA < +125°C, RH < 50%

±150

fA

Input Offset Voltage2, 4

VOS

+8

±40

µV

VCM = 1.5 V to 8.5 V

+9

±50

µV
