Data Sheet
ADA4096-2/ADA4096-4
Rev. G | Page 17 of 25
50
40
30
20
10
0
–10
–20
–30
10
100
1k
10k
100k
1M
10M
–40
FREQUENCY (Hz)
ADA4096-2
VSY = ±15V
TA = 25°C
G = +100
G = +10
G = +1
Figure 40. Closed-Loop Gain vs. Frequency
10k
1k
100
10
1
0.1
10
100
1k
10k
100k
1M
10M
0.01
FREQUENCY (Hz)
ADA4096-2
VSY = ±15V
TA = 25°C
G = +100
G = +10
G = +1
Figure 41. Output Impedance (ZOUT) vs. Frequency
120
100
80
60
40
20
0
10
100
1k
10k
100k
1M
10M
–20
FREQUENCY (Hz)
ADA4096-2
VSY = ±15V
TA = 25°C
PSRR–
PSRR+
Figure 42. PSRR vs. Frequency
15
0
50
100
150
200
250
300
350
400
–15
–10
–5
0
5
10
TIME (µs)
ADA4096-2
VSY = ±15V
TA = 25°C
RL = 10kΩ
CL = 100pF
G = +1
Figure 43. Large Signal Transient Response
