USB0803CSO8PC

Bidirectional TVSarray ™

PRODUCT PREVIEW

SCO TTSD A L E DI VI SI ON

8/20µs 500W Pulse

Figure 1

Peak Pulse Power Vs Pulse Time t = µsec

S Y M B OL S & D E F I NIT I O N S

Symbol

DEFINITION

Stand Off Voltage: Maximum dc voltage that can be applied over the operating temperature range.

Vwm must be selected to be equal or be greater than the operating voltage of the line to be protected

Minimum Breakdown Voltage: The minimum voltage the device will exhibit at a specified current

Clamping Voltage: Maximum clamping voltage across the TVS device when subjected to a given current at a

pulse time of 20 µs.

C

Capacitance: Capacitance of the TVS as defined @ 0 volts at a frequency of 1 MHz and stated in picofarads.

GRAPHS

O U T L I NE A N D S C HE M A T I C

INCHES

MILLIMETERS

MAX

MIN

DIM

MAX

MIN

0.197

A

0.188

4.77

5.00

0.158

0.150

3.81

4.01

0.069

0.053

1.35

1.75

0.021

0.011

0.28

0.53

0.050

0.016

0.41

1.27

0.050 BSC

1.27 BSC

0.010

0.006

0.15

0.25

0.008

0.004

0.10

0.20

0.206

0.189

4.80

5.23

B

C

D

F

G

J

K

L

0.244

P

0.228

5.79

6.19

Figure 2

Pulse Wave Form

OUTLINE

PAD LAYOUT

SCHEMATIC
