1 / 6 page

203 04/00

VHF chokes with ferrite core

Rated voltage 250 V dc/ac

Rated current 0,2 to 2 A

Rated inductance 120 to 3900

µH

Construction

s

Ferrite cylinder core

s

Winding: low-capacitance, multilayer,

enamel copper wire

s

Polyester insulating sleeve

Features

s

High resonance frequency

s

High inductance ratings

Applications

s

RF blocking and filtering

s

Interference suppression in small appliances

Marking

LR and IR in clear text

Delivery mode

Bulk

Dimensional drawing

B82500

VHF Chokes
