Data Sheet

ADCA3280

ABSOLUTE MAXIMUM RATINGS

analog.com

Rev. 0 | 5 of 18

Table 4. Absolute Maximum Ratings

Parameter

Rating

VDD

DC Supply over Voltage (5 minutes)

30 V

RF Input Power (RFINPUT), Single Tone

75 dBmV

Temperature

Operating Range, TPADDLE

−30°C to +100°C

Peak Reflow (Moisture Sensitivity Level (MSL) 3)

260°C

Junction (TJ) to Maintain 1 Million Hour Mean Time

to Failure (MTTF)

170°C

Storage (TS) Range

−40°C to +150°C

Stresses at or above those listed under Absolute Maximum Ratings

may cause permanent damage to the product. This is a stress

rating only; functional operation of the product at these or any other

conditions above those indicated in the operational section of this

specification is not implied. Operation beyond the maximum operat-

ing conditions for extended periods may affect product reliability.

THERMAL RESISTANCE

Thermal performance is directly linked to printed circuit board

(PCB) design and operating environment. Careful attention to PCB

thermal design is required.

θJC is the thermal resistance from the operating portion of the active

device to the exposed paddle on the bottom of the case. See the

Thermal Considerations section for additional information.

Table 5. Thermal Resistance

Package Type

θJC1

Unit

CE-9-4

3.2°C/W

°C/W

1 θJC is defined as between the external TPADDLE and the internal TJ .

ELECTROSTATIC DISCHARGE (ESD) RATINGS

The following ESD information is provided for handling of ESD-sen-

sitive devices in an ESD protected area only.

Human body model (HBM) per ANSI/ESDA/JEDEC JS-001.

ESD Ratings for ADCA3280

Table 6. ADCA3280, 9-Terminal LGA_CAV

ESD Model

Withstand Threshold

Class

HBM

250 V

1A, passed

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Charged devi-

ces and circuit boards can discharge without detection. Although

this product features patented or proprietary protection circuitry,

damage may occur on devices subjected to high energy ESD.

Therefore, proper ESD precautions should be taken to avoid

performance degradation or loss of functionality.
