Data Sheet PL10186EJ03V0DS
11
NX8564/8565/8566LE Series
EA MODULATOR INTEGRATED DFB-LD FAMILY
Absolute Maximum
Ratings
Electro-Optical
Characteristics
Part Number
TC
(
°C)
Tstg
(
°C)
Pf
*1
(mW)
λp
(nm)
Application
Package
MIN.
TYP.
NX8560LJ Series
−20 to +70
−40 to +85
−3 dBm
1 550
*2
10 Gb/s: STM-64
BFY with GPO
TM
−1 dBm
1 550
NX8560MC Series
0 to +75
−40 to +85
−1 dBm
1 550
10 Gb/s: STM-64
19-pin mini BFY
NX8560MCS Series
0 to +75
−40 to +85
−5 dBm
1 550
10 Gb/s: STM-64
19-pin mini BFY
NX8560SJ Series
−5 to +70
−40 to +85
−3 dBm
1 550
*2
10 Gb/s: STM-64
with
λ monitoring PD
BFY with GPO
NX8564LE Series
−20 to +70
−40 to +85
−5 dBm
1 550
*2
2.5 Gb/s: STM-16, 360 km
BFY
NX8565LE Series
−20 to +70
−40 to +85
−5 dBm
1 550
*2
2.5 Gb/s: STM-16, 600 km
BFY
NX8566LE Series
−20 to +70
−40 to +85
0 dBm
1 550
*2
2.5 Gb/s: STM-16, 240 km
BFY
NX8567SA Series
−5 to +70
−40 to +85
−5 dBm
1 550
*2
2.5 Gb/s: STM-16, 600 km
with
λ monitoring PD
BFY
NX8567SAM Series
−5 to +70
−40 to +85
−5 dBm
1 550
*2
2.5 Gb/s: STM-16, 360 km
with
λ monitoring PD
BFY
NX8567SAS Series
−5 to +70
−40 to +85
0 dBm
1 550
*2
2.5 Gb/s: STM-16, 240 km
with
λ monitoring PD
BFY
*1 Under modulation
*2 Available for DWDM Wavelengths based on ITU-T recommendations
