• Intel® Core™ i7/i5/i3 Mobile Processor supports up to 12 Cores, up to 28W

• Intel® Raptor Lake P Mobile Platform

• 2 x DDR5 SODIMM sockets support up to 64GB

• Intel® Iris Xe Graphic/ Intel® UHD Graphics (CPU Dependent)

• 2 x DP++, LVDS

• Supports 3 Independent Displays

• Integrated USB Type C Thunderbolt 4

• 2 x Intel® I226-LM Ethernet Controller (2.5 GbE)

• M.2 E-Key CNVi, M.2 M-Key NVMe, M.2 B-Key with Nano SIM Card Slot

• 4 x USB 3.2, 3 x USB 2.0, 4 x COM Ports, 1 x SATA III

• 12V-24V DC-In

• Fanless Operation (15W CPU)

13th Gen Intel® Core™ i7/i5/i3 Mobile Processor onboard, 3.5” SBC

Ethernet

Controller

2 x Intel® I226-LM Ethernet Controllers

Interface

2 x 10/100/1000/2.5G Base-Tx GbE Compatible

Connector

2 x RJ45

External I/O

Display

2 x DisplayPort++

USB

4 x USB 3.2

Thunderbolt

1 x USB Type C Thunderbolt 4 Connector

LAN

2 x RJ45

DC

1 x Barrel Type DC-In

Internal I/O

Display

1 x LVDS Header

1 x eDP Header (Optional)

USB

2 x USB 2.0 Headers for 3 x USB 2.0 Ports

COM

2 x RS-232/422/485 Headers

2 x RS-232 Headers

SATA

1 x SATA III

GPIO

1 x 8-bits GPIO Header

Other

1 x I²C Header

System

CPU

Intel® Raptor Lake P Mobile Platform

Intel® Core™ i7-1365UE (15W)

Intel® Core™ i5-1345UE (15W)

Intel® Core™ i3-1315UE (15W)

Intel® Core™ i7-1370PE (28W)

Intel® Core™ i5-1350PE (28W)

Intel® Core™ i3-1320PE (28W)

System Memory

2 x SODIMM sockets support DDR 5 4800MHz up to 64GB

BIOS

256Mb SPI BIOS

Expansion

1 x M.2 E-Key 2230, CNVi Support (PCIe x1 Channel & USB Signal)

1 x M.2 M-Key 2280 NVMe (Gen4 PCIe x4)

1 x M.2 B-Key 3042 with Nano SIM Card Socket (with PCIe x2,

SATA, & USB Signal)

Storage through

1 x M.2 (B-Key), 1 x SATA III

TPM

TPM 2.0

Supported OS

Win 10, Win 11 64-bit, Linux Ubuntu

Display

Chipset

Intel® Iris Xe Graphic: select Intel® Core™ i7 and i5 Processors

Intel® UHD Graphics: select Intel® Core™ i3 Processor

Interface

2 x DisplayPort 1.4a @60Hz (4096x2160)

18/24 bits Dual Channel LVDS, eDP optional

Multi-Display

Support 3 Independent Displays

Audio

Chipset

Realtek HD Audio

Amplifier

3W Per Channel Amplifier

ECM-RPLP
