Preliminary Technical Data
SSM2301
SSM2301 STEREO CLASS-D AMPLIFIER EVALUATION MODULE COMPONENT LIST
Table 6.
Reference
Description
Footprint
Quantity
Manufacturer/Part Number
C6, C7
Capacitor, 0.1 μF
0603
2
Murata Manufacturing Co., Ltd./GRM18
C5
Capacitor, 10 μF
0805
1
Murata Manufacturing Co., Ltd./GRM21
C1, C2, C3, C4
Capacitor, 1 nF
0402
4
Murata Manufacturing Co., Ltd./GRM15
R3, R4
Resistor, 100 kΩ
0603
2
Vishay/CRCW06031003F
L1, L2,
Ferrite bead
0402
2
Murata Manufacturing Co., Ltd./BLM15EG121
U1
IC, SSM2301
3.0 mm × 3.0 mm
1
SSM2301CSPZ
EVAL BOARD
PCB evaluation board
1
Rev. PrH | Page 15 of 19
