AD8342

Rev. 0 | Page 6 of 20

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

5.5 V

RF Input Level

12 dBm

LO Input Level

12 dBm

PWDN Pin

IFOP, IFOM Bias Voltage

5.5 V

Minimum Resistor from EXRB to COMM

1.8 kΩ

Internal Power Dissipation

650 mW

77°C/W

Maximum Junction Temperature

135°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational sec-

tion of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on the

human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.
