background image
P9242-R3/RB Datasheet
© 2019 Integrated Device Technology, Inc.
34
May 17, 2019
Table 25. Incoming User Data Registers
Address and Bit
Register Field Name
R/W
Default
Function and Description
0810HEX
Incoming_User_Data_0 RW
00HEX
The external MCU reads this register to get the data that the P9242-R3
received from the P9221-R3.
0811HEX
Incoming_User_Data_1 RW
00HEX
The external MCU reads this register to get the data that the P9242-R3
received from the P9221-R3.
0812HEX
Incoming_User_Data_2 RW
00HEX
The external MCU reads this register to get the data that the P9242-R3
received from the P9221-R3.
0813HEX
Incoming_User_Data_3 RW
00HEX
The external MCU reads this register to get the data that the P9242-R3
received from the P9221-R3.
0814HEX
Incoming_User_Data_4 RW
00HEX
The external MCU reads this register to get the data that the P9242-R3
received from the P9221-R3.
0815HEX
Incoming_User_Data_5 RW
00HEX
The external MCU reads this register to get the data that the P9242-R3
received from the P9221-R3.
0816HEX
Incoming_User_Data_6 RW
00HEX
The external MCU reads this register to get the data that the P9242-R3
received from the P9221-R3.
0817HEX
Incoming_User_Data_7 RW
00HEX
The external MCU reads this register to get the data that the P9242-R3
received from the P9221-R3.
