Ordering information

M24M01-R M24M01-DF

42/47

DocID12943 Rev 14

Ordering information

Table 21. Ordering information scheme

Example:

M24M01 -D

R MN 6

P /K

Device type

M24 = I2C serial access EEPROM

Device function

M01 = 1 Mbit (128 K x 8 bit)

Device family

Blank = Without Identification page

D = With Identification page

Operating voltage

R = VCC = 1.8 V to 5.5 V

F = VCC = 1.7 V to 5.5 V

Package(1)

1. All packages are ECOPACK2® (RoHS compliant and free of brominated, chlorinated and antimony-oxide

flame retardants)

MN = SO8 (150 mil width)

DW = TSSOP8 (169 mil width)

CS = WLCSP

CX = WLCSP ultra thin

Device grade

6 = Industrial: device tested with standard test flow over –40 to 85 °C

Option

T = Tape and reel packing

blank = tube packing

Plating technology

P = ECOPACK2® (RoHS compliant)

Process(2)

2. The process letters apply to WLCSP device only. These process letters appear on the device package

(marking) and on the shipment box. Please contact your nearest ST Sales Office for further information.

/K = Manufacturing technology code
