1 / 21 page

1/21

April 2003

M34D64

64 Kbit Serial I²C Bus EEPROM

With Hardware Write Control on Top Quarter of Memory

FEATURES SUMMARY

s

Two Wire I2C Serial Interface

Supports 400 kHz Protocol

s

Single Supply Voltage:

– 2.5V to 5.5V for M34D64-W

– 1.8V to 5.5V for M34D64-R

s

Hardware Write Control of the top quarter of

memory

s

BYTE and PAGE WRITE (up to 32 Bytes)

s

RANDOM and SEQUENTIAL READ Modes

s

Self-Timed Programming Cycle

s

Automatic Address Incrementing

s

Enhanced ESD/Latch-Up Behavior

s

More than 1M Erase/Write Cycles

s

More than 40 Year Data Retention

Figure 1. Packages

SO8 (MN)

150 mil width

8

1

TSSOP8 (DW)

169 mil width
