 2 / 6 page
background image
www.advantech.com/products
Online Download
Dimensions
Unit: mm
EPC-C301
Ordering Information
Part Number
CPU
Max. Frequency
Core
Memory
Storage
OS
Adapter
AI Accelerator Card
Operating Temp
EPC-C301EVK-S7A1
i7-8665UE
4.40 GHz
4
16GB (Dual Channel)
128G SATA SSD
Ubuntu v18.04
Yes
Yes (VEGA-330)
-20 ~ 50 degree
EPC-C301C7-S7A1
i7-8665UE
4.40 GHz
4
16GB (Dual Channel)
128G SATA SSD
N/A
No
No
-20 ~ 60 degree
EPC-C301EVK-S6A1
i5-8365UE
4.10 GHz
4
8GB (Single Channel)
128G SATA SSD
Ubuntu v18.04
Yes
Yes (VEGA-330)
-20 ~ 50 degree
EPC-C301C5-S6A1
i5-8365UE
4.10 GHz
4
8GB (Single Channel)
128G SATA SSD
N/A
No
No
-20 ~ 60 degree
Packing List
Part No.
Description
Quantity
EPC-C301
1
Quick Start Guide (for EVK SKU only)
1
China RoHS
1
Optional Accessories
Part No.
Description
96PSA-A120W12W7-3
Adapter 100-240V 120W 12V, LOCKABLE DC JACK
1702002600-01
Power cable 3-pin 183 cm, USA type
1700018704
Power cable 3-pin 180 cm, UK type
1702002605
Power cable 3-pin 183 cm, Europe type
1700000237-01
Power cable 3-pin 183 cm, PSE type
Embedded OS/API
Embedded OS/API
Part No.
Description
Win10
(High End for Core i7)
20706WX9HS0135
img W10 19HL EPC-C301 64b 1809 ENU
Win10
(Value for Core i5/i3)
20706WX9VS0139
img W10 19VL EPC-C301 64b 1809 ENU
Ubuntu v18.04
36OSC301000101
Ubuntu V18.04 image w/ Intel OpenVINO
Toolkit
Ubuntu v20.04
20706U20DS0002
img Ubun20.4 EPC-C301 64b 2004 ENU
Software API
N/A
SUSI 4.0/iManager 3.0
Software API
N/A
WISE-PaaS/DeviceOn
Front Panel External I/O Mechanical
Layout/Drawing
Side Panel External I/O mechanical
Layout/ Drawing
USB 3.0
COM1
LAN2 ON/OFF
SIM
ANT COM4 CAN1 ANT
COM3
DIO
CAN2
HDMI
LAN1 DC IN
USB 2.0
COM2
DP
LAN3
MIC
LAN4 Line Out
170
118
