Fanless Embedded Box PCs

Features

ARK-10 A4

Intel® Celeron Quad Core J1900 Quad

Core SoC with Dual GbE and Dual COM

Fanless Box PC

Intel® Celeron J1900 Quad Core 2.0 GHz SoC

2G DDR3L Memory & 500G 2.5" 24x7 SATA HDD Built In

2 x GbE for Multiple Internet Transmission

2 x RS-232/422/485 (BIOS selection)

1 x Full-Size MiniPCIe (ex. WLAN or WWAN module) #1

Optional VESA / DIN Rail / Wall Mounting kits

Threaded DC jack design

Supports WISE-PaaS DeviceOn and Embedded Software APIs

Specifications

ARK-10-U0A4

Processor System

CPU

Intel® Celeron Processor J1900 Quad Core SoC

Frequency

2.0 GHz (Up to 2.41 GHz w/ burst frequency enabled)

L2 Cache

2 MB

BIOS

AMI EFI 64 Mbit (Default BIOS is supported for 64-bit OS installation, BIOS for 32-bit OS is supported by project)

Memory

Technology

DDR3L 1333 MHz

Socket

1 x 204-pin SO-DIMM, 2 GB Memory Built In

Graphics

Chipset

Intel® Atom SoC integrated

Graphic Engine

DirectX* 11.1, OGL 3.0, OCL 1.1, OGL ES 2.0

Encode: H264, MPEG2/4, VC1, WMV9

Decode: H264, MPEG2

VGA

1 x VGA, support up to 1920 x 1200 at 60Hz

Audio

Main System

ALC-888S, High Definition Audio. Line-out & Line-in

Ethernet

LAN #1

10/100/1000 Mbps Intel I210 GbE, support Wake on LAN

LAN #2

10/100/1000 Mbps Intel I210 GbE, support Wake on LAN

I/O Interface

Serial Ports

2 x RS-232/422/485 (BIOS selectable)

USB Interface

2 x USB 2.0 & 1 x USB3.0

Other

Watchdog timer

255-level timer interval, setup by software

Expansion

Mini PCIe

1 x Full-size Mini PCIe, support WLAN or WWAN module #1

Storage

2.5" Drive Bay

1 x 500GB 2.5" 24x7 SATA HDD Built In

mSATA

1x half-size mSATA (Suggest to assembly by CTOS or T-Part due to complex installation)

Software Support

Microsoft Windows

Windows 10

Linux

Support (by Project)

Power Requirement

Power Input Voltage

Single 12 VDC

Power Adapter

AC to DC, DC12 V/3 A, 36 W with threaded design

Mechanical

Construction

Aluminum housing

Mounting

VESA/DIN Rail/Wall Mounting Kits (Optional)

Dimensions (W x H x D)

133.8 x 43.1 x 94.2 mm (5.27" x 1.7" x 3.71")

Environment

Operating Temperature

0 ~ 50° C with 0.7m/s air flow

Storage Temperature

-40 ~ 85 °C (-40~185 °F)

Relative Humidity

95% @ 40 °C (non-condensing)

Vibration During Operation

0.5Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

Shock During Operation

10G, IEC 60068-2-27, half sine, 11 ms duration

Regulation

EMC

CE/FCC Class A, CCC, BSMI, UKCA

Safety

UL, CCC, BSMI, CB, UKCA

#1 Mini PCIe is hardware interface for wireless communication integration only. System level RF certification is not available.

RoHS

COMPLIANT

2002/95/EC

All product specifications are subject to change without notice.

Last updated: 8-Sep-2022
