Table 6-1. Pin Attributes (ALV Package) (continued)

BALL

NUMBER [1]

BALL NAME [2]

PADCONFIG Register [15]

PADCONFIG Address [16]

SIGNAL NAME [3]

MUX

MODE

[4]

TYPE

[5]

DSIS

[6]

BALL

STATE

DURING

RESET

RX/TX/PULL [7]

BALL

STATE

AFTER

RESET

RX/TX/PULL [8]

MUX

MODE

AFTER

RESET

[9]

I/O

OPERATING

VOLTAGE [10]

POWER [11]

HYS

[12]

BUFFER

TYPE [13]

PULL

UP/DOWN

TYPE [14]

J10, J12,

K11, K9, L12,

L8, M11, M9,

N10, N8, P9

VDD_CORE

PWR

H14

VDD_DLL_MMC0

PWR

K13

VDD_MMC0

PWR

K16

VMON_1P8_MCU

E12

VMON_1P8_SOC

F13

VMON_3P3_MCU

F14

VMON_3P3_SOC

K10

VMON_VSYS

G15

VPP

PWR

A1, A21, A5,

A6, AA1,

AA15, AA18,

AA21, C10,

C15, C3, D1,

E11, E13,

F10, F15, F8,

G1, G16, G3,

G7, G9, H11,

H20, H21,

H6, H8, J14,

J7, J9, K6,

K8, L1, L16,

L3, L7, L9,

M10, M12,

M6, M8, N11,

N13, N15,

N7, N9, P1,

P10, P18, P6,

P8, R12, R7,

R9, T10, T11,

T15, T16, T8,

U3, V17,

W10, W18,

Y14, Y17,

Y19

VSS

GND
