Single-Ended Cordsets

BCC M424-0000-2A-008-VX8434-050

Order Code: BCC035P

Internet

www.balluff.com

eCl@ss 9.1: 27-06-03-11

Subject to change without notice: 239063

ETIM 6.0: EC001855

BCC035P_2.5_2021-03-18

1 / 2

Basic features

Approval/Conformity

CE

cULus

EAC

WEEE

Display/Operation

Function indicator (Pin 4)

LED yellow

Power indicator

Green LED

Electrical connection

Bending radius min., fixed cable

5 x D

Bending radius min., flexible cable

10 x D

Cable

PVC gray, 5 m, drag chain

compatible

Cable diameter D

4.80 mm ±0.15 mm

Cable, bending cycles min.

2 mil.

Conductor cross-section

0.34 mm²

Connection

M12x1-Male, angled, 4-pin, A-

coded

Connector configuration

right-angle

Number of conductors

4

Number of pins

4

System

Molded

Electrical data

Operating voltage Ub

30 VDC

Rated current (40 °C)

4.0 A

Environmental conditions

Cable temperature UL max., fixed

routing

80 °C

Cable temperature UL max., flexible

routing

80 °C

Cable temperature, drag chain

-5...60 °C

Cable temperature, fixed routing

-40...105 °C

Cable temperature, flexible routing

-5...105 °C

IP rating

IP67, IP68, IP69K

Interface

Switching output

PNP NO/NC antivalent

Material

Cable jacket, material

PVC

Material contact carrier

PUR

Material contacts

Brass

Material cover nut

Die-cast zinc

Material grip

PUR

Mechanical data

Acceleration max., drag chain

5 m/s²

Cable jacket, color

gray

Cable length L

5.00 m

Cable properties

drag chain compatible

Horizontal travel permitted, drag

chain

5 m

Tightening torque pigtail

0.6 Nm

Traverse speed max., drag chain

200 m/min

Vertical travel permitted, drag chain

2 m
