Mechanical Cam Switches

BSE 30.0-RK

Order Code: BSE0005

Internet

www.balluff.com

eCl@ss 9.1:

Subject to change without notice: 145364

ETIM 6.0:

BSE0005_2_2022-05-17

2 / 2

Use with series

EGT F60

RGT 100

RGT 61

RGT 62

RGT 72

Electrical connection

Connection

Connection type

1. Switch position: Screw terminal

Contact system

Dual changeover

One NO and one NC

galvanically isolated

Double-interrupting

Electrical data

Contact arrangement

NC: 21+22

NO: 13+14

Contact resistance max.

40 mOhm

Contact resistance max., note

New condition

Continuous current

1. Switch position: 6.0 A

Mechanical life expectancy min.

30 mil. switching operations

Minimum load at 24 V DC

20.0 mA

Nominal voltage

250 VAC

Switching actuation force max.

4.80 N

Switching capacity at 220 V DC

0.5 A, L/R = 200ms

Switching capacity at 24 V DC

4 A, L/R = 200 ms

Switching capacity at 250 V AC

40...60Hz

6 A cos φ = 1

2 A cos φ = 0.8

1 A cos φ = 0.4

Switching operations per minute

300

Switching principle

Snap switch, self-cleaning

Switchover time max.

10.0 ms

Environmental conditions

Ambient temperature

-5...85 °C

Material

Cover material

Thermoplast

Housing material

Thermoplast, GF

Material contacts

Silver, gold plated

Material contacts

1. Switch position: Silver, gold

plated

Mechanical data

Connection cross-section

1.5 mm²

Switching actuation force min.

3.60 N

Tightening torque max.

120 Ncm
