background image
Data Sheet
ADPA7008
SPECIFICATIONS
analog.com
Rev. 0 | 4 of 28
40 GHZ TO 50 GHZ FREQUENCY RANGE
TA = 25°C, VDD = 5 V, IDQ = 1500 mA, and 50 Ω matched input and output, unless otherwise noted. Adjust VGG1 from −1.5 V to −0.4 V to
achieve IDQ = 1500 mA typical.
Table 3.
Parameter
Symbol
Min
Typ
Max
Unit
Test Conditions/Comments
FREQUENCY RANGE
40
50
GHz
GAIN
16
dB
Gain Flatness
±1.1
dB
Gain Variation Over Temperature
0.039
dB/°C
NOISE FIGURE
7
dB
RETURN LOSS
Input
15
dB
Output
13
dB
OUTPUT
Output Power for 1 dB Compression
P1dB
27.5
dBm
Saturated Output Power
PSAT
29
dBm
Output Third-Order Intercept
IP3
36
dBm
POUT per tone = 14 dBm with 1 MHz tone spacing
POWER ADDED EFFICIENCY
PAE
7
%
Measured at PSAT
SUPPLY
Quiescent Current
IDQ
1500
mA
Adjust VGG1, from −1.5 V up to −0.4 V to achieve the desired IDQ,
VGGx = −0.63 V typical to achieve IDQ= 1500 mA
Voltage
VDD
4
5
V
50 GHZ TO 54 GHZ FREQUENCY RANGE
TA = 25°C, VDD = 5 V, IDQ = 1500 mA, and 50 Ω matched input and output, unless otherwise noted. Adjust VGG1 from −1.5 V to −0.4 V to
achieve IDQ = 1500 mA typical.
Table 4.
Parameter
Symbol
Min
Typ
Max
Unit
Test Conditions/Comments
FREQUENCY RANGE
50
54
GHz
GAIN
15.5
dB
Gain Flatness
±1.0
dB
Gain Variation Over Temperature
0.049
dB/°C
RETURN LOSS
Input
10
dB
Output
9
dB
OUTPUT
Output Power for 1 dB Compression
P1dB
24.5
dBm
Saturated Output Power
PSAT
27
dBm
Output Third-Order Intercept
IP3
35
dBm
POUT per tone = 14 dBm with 1 MHz tone spacing
POWER ADDED EFFICIENCY
PAE
4
%
Measured at PSAT
SUPPLY
Quiescent Current
IDQ
1500
mA
Adjust VGG1, from −1.5 V up to −0.4 V to achieve the desired IDQ,
VGGx = −0.63 V typical to achieve IDQ = 1500 mA
Voltage
VDD
4
5
V
