TM5SDO2R Folha de dados(PDF) 7 Page - Schneider Electric

Nome de Peças TM5SDO2R
Descrição Electrónicos  Discrete output module, Modicon TM5, digital 2O, 30 V DC/230 V AC, 5 A, relay, 2 C/O
PDF  7 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Fabricante Electrônico  SCHNEIDER [Schneider Electric]
Página de início  https://www.se.com/us/en/
Logo SCHNEIDER - Schneider Electric

TM5SDO2R Folha de dados(HTML) 7 Page - Schneider Electric

  TM5SDO2R Datasheet HTML 1Page - Schneider Electric TM5SDO2R Datasheet HTML 2Page - Schneider Electric TM5SDO2R Datasheet HTML 3Page - Schneider Electric TM5SDO2R Datasheet HTML 4Page - Schneider Electric TM5SDO2R Datasheet HTML 5Page - Schneider Electric TM5SDO2R Datasheet HTML 6Page - Schneider Electric TM5SDO2R Datasheet HTML 7Page - Schneider Electric
Zoom Inzoom in Zoom Outzoom out
 7 / 7 page
background image
Product data sheet
Connections and Schema
TM5SDO2R
Electronic Module 2DO 30 Vdc/230 Vac 5 A Relay C/O
Wiring Diagram
(1)
Internal electronics
(2)
24 Vdc I/O power segment integrated into the bus bases
(3)
External power supply 100...240 Vac
(4)
Inductive load protection
(5)
2-wire load
(6)
External power supply 24 Vdc
(7)
External fuse type T slow-blow 5 A - 250 V
Apr 6, 2022
