11/05/2018   Page 1 / 3

Printed-circuit board connector - MCVU 1,5/10-GFD-3,81 AU - 1840887

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Direct plug-in block, nominal current: 8 A, number of positions: 10, pitch: 3.81 mm, connection method: Screw

connection with tension sleeve, color: green, contact surface: Gold

Your advantages

 Gold-plated contacts ensure transfer quality remains stable over the long term

 Screwable flange for superior mechanical stability

 Laterally mounted flange for screw connection in the housing or on the mounting plate

 Maximum flexibility when it comes to device design – one header for connectors with different connection technologies

Key Commercial Data

Packing unit

50 pc

GTIN

GTIN

4017918227432

Technical data

Dimensions

Pitch

3.81 mm

Dimension a

34.29 mm

Height

13 mm

General

Range of articles

MCVU 1,5/..-GFD

Rated voltage (III/3)

160 V

Connection in acc. with standard

EN-VDE

8 A

Color

green

Number of positions

10

Standards and Regulations

Connection in acc. with standard

EN-VDE

CSA

Environmental Product Compliance

REACh SVHC

Lead 7439-92-1

China RoHS

Environmentally Friendly Use Period = 50
