E5EC-800

Isolation/Insulation Block Diagrams

Models with 2 Auxiliary Outputs

Nomenclature

Communications and event inputs

Sensor input and CT input

Voltage output (for driving SSR) and current output

Relay output

Auxiliary output 1

Auxiliary output 2

: Reinforced insulation

: Functional isolation

Power

Supply

E5EC

Top View

Temperature unit

Operation indicators

Shift (PF) key

No.1 display

No. 2 display

No. 3 display

Down key

Up key

Mode key

Level key
