 20 / 24 page
background image
20/24
¡ Semiconductor
MSM66585/586/587/P587/Q587
• Serial Port Control
Master mode
Serial clock cycle time
Symbol
Units
Conditions
Parameter
Min.
Output data setup time
Output data hold time
Input data setup time
Input data hold time
tfW
tSRMXS
ns
(Ta=–30 to +70°C)
Clock (OSC) pulse width
50
CL=50pF
8tfW
4tfW–10
3tfW–20
30
0
Typ.
—
—
—
—
—
—
tSCKC
tSTMXS
tSTMXH
tSRMXH
—
Max.
—
—
—
—
—
—
tSCKC
SDOUT
(TXD)
tSTMXH
SDIN
(RXD)
tSRMXS
SCK
tSTMXS
tSRMXH
Valid
Valid
